Small Test Facility For Small Components Up To 30 Mm In Size

The small test device KPE 30 from Feinmess Suhl should be suitable for a safe, high-precision measurement of cylindrical and spherical components and measurement objects up to a size of 30 mm by adhering to the Abbe measurement principle. According to the manufacturer, the stable, heavy body made of mineral casting eliminates almost all external influences. Thanks to its compact design, the test facility should find its place flexibly in the measuring room and should also be recommended as an instrument for mobile use. According to the manufacturer, the weight of the overall system is 11 kg.

Extensive accessories

Various expanded accessories for the KPE 30 should enable the calibration of pins, plug gauges or thread gauges. According to Feinmess Suhl, the 2-channel display unit PU26 offers a variable display mode as well as the communication interface via USB or RS232 to the following computer systems. The FMS-View software enables visualization and further processing in Microsoft Excel.

Feinmess Suhl also shows the digital parameter 3902, which with its robust measuring body and a new type of inductive measuring system is said to offer very high measuring accuracy. The weight of the measuring device lies on the workpiece thanks to the anvil, which can be adjusted from above. The measuring probe brought up from below, which has a measuring stroke of 4 mm, ensures a very high repeatability due to its constant measuring force, assures Feinmess Suhl.

The display resolution is 0.1 μm. Large measuring surfaces with a diameter of 10 mm would ensure stable contact with the test object, according to the manufacturer. The user should be able to process the measured values ​​externally with an optional radio module. The adjustable tolerance mode also simplifies use in series measurement. (jv)

Control 2017: Hall 3, booth 3311
